link to page 4 F2HALFBR Module Product Preview NXH006P120MNF2PTG The NXH006P120MNF2 is a power module containing an 6 mW /1200 V SiC MOSFET half−bridge and a thermistor in an F2 package.
www.onsemi.com Features
• 6 mW /1200 V SiC MOSFET Half−bridge • Thermistor
PACKAGE PICTURE
• Options with Pre−applied Thermal Interface Material (TIM) and without Pre−applied TIM • Options with Solderable Pins and Press−fit Pins • These Devices are Pb−Free, Halide Free and are RoHS Compliant
Typical Applications
• Solar Inverter • Uninterruptible Power Supplies • Electric Vehicle Charging Stations
PIM36 56.7x42.5 (PRESS FIT)
• Industrial Power
CASE 180BY MARKING DIAGRAM
NXH006P120MNF2PTG ATYYWW XXXXX = Specific Device Code AT = Assembly & Test Site Code YWW = Year and Work Week Code
PIN CONNECTIONS Figure 1. NXH006P120MNF2 Schematic Diagram
