HMC936ALP6E. GaAs MMIC 6 BIT DIGITAL. PHASE SHIFTERS, 1.2 - 1.4 GHz. Evaluation PCB
Modelllinie für dieses Datenblatt
Textversion des Dokuments
HMC936ALP6E
v03.0117
GaAs MMIC 6 BIT DIGITAL PHASE SHIFTERS, 1.2 - 1.4 GHz Evaluation PCB
T M L - S ITA IG S - D R E T IF H E S S A H P
List of Materials for Evaluation PCB EV1HMC936ALP6 [1][3]
The circuit board used in the application should use Item Description RF circuit design techniques. Signal lines should J1 - J2 PCB Mount SMA RF Connector have 50 ohm impedance while the package ground J3 Header 2mm, 16 Pin leads and exposed paddle should be connected C1, C2 1000 pF Capacitor, 0402 Pkg. directly to the ground plane similar to that shown. U1 HMC936ALP6E 6-Bit Digital Phase Shifter A sufficient number of via holes should be used to PCB [2] 117718 Evaluation PCB connect the top and bottom ground planes. The [1] Reference this number when ordering complete evaluation PCB evaluation board should be mounted to an appro- [2] Circuit Board Material: Rogers 4350 priate heat sink. The evaluation circuit board shown [3] Please refer to part’s pin description and functional diagram for pin out assignments on evaluation board. is available from Analog Devices upon request. For price, delivery, and to place orders: Analog Devices, Inc., One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106 Phone: 781-329-4700 • Order online at www.analog.com Application Support: Phone: 1-800-ANALOG-D
