PIC16(L)F191XX
• Complementary Waveform Generator (CWG):
Flexible Oscillator Structure:
- Rising and falling edge dead-band control - Full-bridge, half-bridge, 1-channel drive • High-Precision Internal Oscillator: - Multiple signal sources - Active clock tuning of HFINTOSC over • Two Capture/Compare/PWM (CCP) module voltage and temperature • Two 10-bi t PWMs - Selectable frequency range up to 32 MHz • Peripheral Pin Select (PPS): - ±1% typical - Enables pin mapping of digital I/O • x2/x4 PLL with Internal and External Sources • Communication: • Low-Power Internal 32 kHz Oscillator - Two EUSART, RS-232, RS-485, LIN (LFINTOSC) compatible • External 32 kHz Crystal Oscillator (SOCS) - One SPI • External Oscillator Block with: - One I2C, SMBus, PMBus™ compatible - Three external clock modes up to 20 MHz • Up to 59 I/O Pins - Fail-Safe Clock Monitor • Individually Programmable Pull-ups - Al ows for safe shutdown if peripherals clock • Slew Rate Control stops • Interrupt-on-Change with Edge-Select - Oscillator Start-up Timer (OST) • Input Level Selection Control (ST or TTL) - Ensures stability of crystal oscillator sources • Digital Open-Drain Enable • Current-mode Enable
Analog Peripherals:
• Analog-to-Digital Converter with Computation (ADC2): - 12-bit with up to 47 external channels - Automated post-processing - Automates math functions on input signals: averaging, filter calculations, oversampling and threshold comparison - Conversion available during Sleep • Two Comparators: - (1) Low-Power Comparator - (1) High-Speed Comparator - Fixed Voltage Reference at non-inverting input(s) - Comparator outputs externally accessible • 5-Bit Digital-to-Analog Converter (DAC): - 5-bit resolution, rail-to-rail - Positive Reference Selection - Unbuffered I/O pin output - Internal connections to ADCs and comparators • Voltage Reference: - Fixed Voltage Reference with 1.024V, 2.048V and 4.096V output levels  2016 Microchip Technology Inc. DS40001863A-page 2 Document Outline Description: Core Features: Memory: Operating Characteristics: Power-Saving Functionality: eXtreme Low-Power (XLP) Features: Digital Peripherals: Analog Peripherals: Flexible Oscillator Structure: TABLE 1: PIC16(L)F191XX Family Types TABLE 2: Packages Pin Diagrams FIGURE 1: 28-Pin SSOP, SPDIP and SOIC package Diagram for PIC16(L)F19155/56 FIGURE 2: 28-Pin UQFN Package Diagram For PIC16(L)F19155/56 FIGURE 3: 40-Pin PDIP Package Diagram For PIC16(L)F19175/76 FIGURE 4: 40-Pin UQFN (5x5X0.5) Package Diagram For PIC16(L)F19175/76 FIGURE 5: 44-Pin TQFP package Diagram for PIC16(L)F19175/76 FIGURE 6: 44-Pin QFN (8x8X0.9) Package Diagram For PIC16(L)F19175/76 FIGURE 7: 48-Pin TQFP/UQFN package Diagram for PIC16(L)F19185/86 FIGURE 8: 64-Pin TQFP/QFN package Diagram for PIC16(L)F19195/96/97 TABLE 3: 28-Pin Allocation Table (PIC16(L)F19155/56) TABLE 4: 40/44-Pin Allocation Table (PIC16(L)F19175/76) TABLE 5: 48-Pin Allocation Table (PIC16(L)F19185/86) TABLE 6: 64-Pin Allocation Table (PIC16(L)F19195/96/97) Trademarks Worldwide Sales
