LT1815/LT1816/LT1817
ELECTRICAL CHARACTERISTICS The
l
denotes the specifi cations which apply over the full operating temperature range, otherwise specifi cations are at TA = 25°C (Note 8). VS = ±5V, VCM = 0V, unless otherwise noted. For the programmable current option (LT1815S6 or LT1816A), the ISET pin must be connected to V– through 75Ω or less, unless otherwise noted. SYMBOL PARAMETER CONDITIONS MIN TYP MAX UNITS
GBW Gain-Bandwidth Product f = 200kHz, RL = 500Ω, LT1815 150 220 MHz TA = 0°C to 70°C l 140 MHz TA = –40°C to 85°C l 130 MHz f = 200kHz, RL = 500Ω, LT1816/LT1817 140 220 MHz TA = 0°C to 70°C l 130 MHz TA = –40°C to 85°C l 120 MHz Gain-Bandwidth Product LT1815S6/LT1816A; 40kΩ Between ISET and V–; (Low Power Mode) (Note 10) f = 200kHz, RL = 500Ω 35 55 MHz TA = 0°C to 70°C l 30 MHz TA = –40°C to 85°C l 25 MHz –3dB BW –3dB Bandwidth AV = 1, RL = 500Ω 350 MHz tr, tf Rise Time, Fall Time AV = 1, 10% to 90%, 0.1V, RL = 100Ω 1 ns tPD Propagation Delay AV = 1, 50% to 50%, 0.1V, RL = 100Ω 1.4 ns OS Overshoot AV = 1, 0.1V; RL = 100Ω 25 % tS Settling Time AV = –1, 0.1%, 5V 15 ns THD Total Harmonic Distortion AV = 2, f = 5MHz, VOUT = 2VP-P, RL = 500Ω –70 dB dG Differential Gain AV = 2, VOUT = 2VP-P, RL = 150Ω 0.08 % dP Differential Phase AV = 2, VOUT = 2VP-P, RL = 150Ω 0.04 Deg ROUT Output Resistance AV = 1, f = 1MHz 0.20 Ω IS Supply Current LT1815 6.5 7 mA TA = 0°C to 70°C l 9 mA TA = –40°C to 85°C l 10 mA LT1816/LT1817, per Amplifi er 6.5 7.8 mA TA = 0°C to 70°C l 10.5 mA TA = –40°C to 85°C l 11.5 mA Supply Current (Low Power Mode) LT1815S6/LT1816A, 40kΩ Between ISET and V–, (Note 10) per Amplifi er 1 1.5 mA TA = 0°C to 70°C l 1.8 mA TA = –40°C to 85°C l 2.0 mA ISET ISET Pin Current (Note 10) LT1815S6/LT1816A –150 –100 μA TA = 0°C to 70°C l –175 μA TA = –40°C to 85°C l –200 μA 181567fb 5
