LT1884/LT1885
W W W U ABSOLUTE AXI U RATI GS (Note 1)
Supply Voltage (V+ to V –) ... 40V Operating Temperature Range (Note 4) .. – 40°C to 85°C Differential Input Voltage (Note 2) ... ±10V Specified Temperature Range (Note 5) ... – 40°C to 85°C Input Voltage .. V+ to V – Maximum Junction Temperature .. 150°C Input Current (Note 2) .. ±10mA Storage Temperature Range ... – 65°C to 150°C Output Short-Circuit Duration (Note 3) .. Indefinite Lead Temperature (Soldering, 10 sec).. 300°C
U W U PACKAGE/ORDER I FOR ATIO
ORDER ORDER PART NUMBER PART NUMBER TOP VIEW TOP VIEW LT1884CN8 LT1885CS LT1884CS8 OUT A 1 14 OUT D LT1885IS OUT A 1 8 V+ LT1884ACN8 – IN A 2 13 –IN D A D –IN A 2 7 OUT B +IN A 3 12 +IN D A LT1884ACS8 +IN A 3 6 –IN B V+ 4 11 V– B LT1884IN8 V – 4 5 +IN B +IN B 5 10 +IN C LT1884IS8 B C –IN B 6 9 –IN C N8 PACKAGE S8 PACKAGE 8-LEAD PDIP 8-LEAD PLASTIC SO LT1884AIN8 OUT B 7 8 OUT C LT1884AIS8 TJMAX = 150°C, θJA = 130°C/W (N8) S PACKAGE TJMAX = 150°C, θJA = 190°C/W (S8) 14-LEAD PLASTIC SO S8 PART MARKING TJMAX = 150°C, θJA = 110°C/W 1884 1884I 1884A 1884AI Consult factory for Military grade parts.
ELECTRICAL CHARACTERISTICS The
●
denotes the specifications which apply over the full operating temperature range, otherwise specifications are at TA = 25
°
C. Single supply operation VEE = 0, VCC = 5V; VCM = VCC/2 unless otherwise noted. (Note 5) SYMBOL PARAMETER CONDITIONS MIN TYP MAX UNITS
VOS Input Offset Voltage (LT1884A) 25 50 µV 0°C < TA < 70°C ● 85 µV – 40°C < TA < 85°C ● 110 µV Input Offset Voltage (LT1884/LT1885) 30 80 µV 0°C < TA < 70°C ● 125 µV – 40°C < TA < 85°C ● 150 µV Input Offset Voltage Drift (Note 6) 0°C < TA < 70°C ● 0.3 0.8 µV/°C – 40°C < TA < 85°C ● 0.3 0.8 µV/°C IOS Input Offset Current (LT1884A) 100 300 pA 0°C < TA < 70°C ● 400 pA – 40°C < TA < 85°C ● 500 pA Input Offset Current (LT1884/LT1885) 150 900 pA 0°C < TA < 70°C ● 1200 pA – 40°C < TA < 85°C ● 1400 pA 2
