Datasheet Wago 722-142/005-000/039-000 — Datenblatt
Female connector for rail-mount terminal blocks; straight; 100% protected against mismating; Locking lever; Pin spacing 5 mm; 12-pole
Preise
Detaillierte Beschreibung
Parameter
| Color | light gray |
| Connector connection type | for front-entry wiring terminal block |
| Contact material | Copper alloy |
| Contact plating | tin-plated |
| Contact type (pluggable connector) | Female connector/socket |
| Страна происхождения | DE |
| Depth | 11.6 mm / 0.457 inch |
| Flammability class per UL94 | V0 |
| Global Trade Item Number (GTIN) | 4055143372909 |
| Height | 36.1 mm / 1.421 inch |
| Height from the surface | 21.6 mm / 0.85 inch |
| Insulating material | Polyamide 66 (PA 66) |
| Legend (ratings) | (III / 2) ≙ Overvoltage category III / Pollution degree 2 |
| Limit temperature range | -60 … +85 °C |
| Locking of plug-in connection | locking lever |
| Material group | I |
| Mismating protection | Yes |
| Number of Poles | 12 |
| Number of levels | 1 |
| Pin spacing | 5 mm (0.197 inch) |
| Rated current | 12 A |
| Rated impulse voltage (II / 2) | 4 kV |
| Rated impulse voltage (III / 2) | 4 kV |
| Rated impulse voltage (III / 3) | 4 kV |
| Rated voltage (II / 2) | 630 V |
| Rated voltage (III / 2) | 320 V |
| Rated voltage (III / 3) | 320 V |
| Steckrichtung zur Reihenklemme | 90 ° |
| Total number of potentials | 12 |
| Weight | 13.52 g |
| Width | 75.8 mm / 2.984 inch |
