Datasheet Wago 231-116/027-000 — Datenblatt
1-conductor female plug; clamping collar; 2.5 mm²; Pin spacing 5 mm; 16-pole
Preise
Detaillierte Beschreibung
Parameter
| Actuation type | Operating tool |
| Clamping spring material | Chrome nickel spring steel (CrNi) |
| Color | gray |
| Connection technology | CAGE CLAMP® |
| Connector connection type | for conductors |
| Contact material | Copper alloy |
| Contact plating | tin-plated |
| Contact type (pluggable connector) | Female connector/socket |
| Страна происхождения | DE |
| Depth | 26.45 mm / 1.041 inch |
| Fine-stranded conductor | 0.08 … 2.5 mm² / 28 … 12 AWG |
| Fine-stranded conductor with ferrule with plastic collar | 0.25 … 1.5 mm² |
| Fine-stranded conductor with ferrule without plastic collar | 0.25 … 2.5 mm² |
| Fire load | 0.431 MJ |
| Flammability class per UL94 | V0 |
| Global Trade Item Number (GTIN) | 4044918342278 |
| Height | 14.3 mm / 0.563 inch |
| Insulating material | Polyamide 66 (PA 66) |
| Legend (ratings) | (III / 2) ≙ Overvoltage category III / Pollution degree 2 |
| Limit temperature range | -60 … +85 °C |
| Material group | I |
| Mismating protection | No |
| Mounting type | Mounting flange |
| Number of Poles | 16 |
| Number of connection types | 1 |
| Number of levels | 1 |
| Pin spacing | 5 mm (0.197 inch) |
| Product Group | 3 (Multi Conn. System) |
| Rated current | 16 A |
| Rated impulse voltage (II / 2) | 4 kV |
| Rated impulse voltage (III / 2) | 4 kV |
| Rated impulse voltage (III / 3) | 4 kV |
| Rated voltage (II / 2) | 630 V |
| Rated voltage (III / 2) | 320 V |
| Rated voltage (III / 3) | 320 V |
| Solid conductor | 0.08 … 2.5 mm² / 28 … 12 AWG |
| Strip length | 8 … 9 mm / 0.31 … 0.35 Inch |
| Total number of connection points | 16 |
| Total number of potentials | 16 |
| Type of mounting | Feed-through mounting Panel mounting |
| Weight | 29.328 g |
| Width | 94.8 mm / 3.732 inch |
| with reinforcing strip | 1 |
